| Fig. | Part Number | Description | Unit/Price | Add to Cart |
|---|---|---|---|---|
| 1 | 623756 | Cylinderhead 2/3 Assy. | $1,047.57 | Add to Cart |
| 2 | 623766 | Cylinderhead 1/4 Assy. | $1,049.48 | Add to Cart |
| 3 | 881920 | O-ring Set | $55.67 | Add to Cart |
| 4 | Washer 8,4 | $0.21 | Add to Cart | |
| 5 | Valve Cover Sky Blue | $118.63 | Add to Cart | |
| 6 | Cylinderhead 2/3 Assy. | $2,096.22 | Add to Cart | |
| 7 | Cylinderhead 1/4 Assy. | $2,151.32 | Add to Cart | |
| 8 | Valve Guide 912s | $21.31 | Add to Cart | |
| 9 | 230810 | Valve Stem Seal | $5.27 | Add to Cart |
| 10 | Retaining Ring A12 Din 7999 | $0.59 | Add to Cart | |
| 11 | Sealing Ring A12x18 Din 7603 | $0.37 | Add to Cart | |
| 12 | 250285 | O-ring 105×2,5 | $9.57 | Add to Cart |
| 13 | 253092 | Valve Cotter | $3.75 | Add to Cart |
| 14 | Inlet Valve Guide | $19.78 | Add to Cart | |
| 15 | 430205 | O-ring 6,4×1,8 | $0.45 | Add to Cart |
| 16 | 431570 | O-ring 10,82×1.78-n | $0.45 | Add to Cart |
| 17 | Valve Cover | $112.01 | Add to Cart | |
| 18 | Cylinderhead 2/3 Assy. | $1,082.84 | Add to Cart | |
| 19 | 623784 | Cylinderhead 1/4 Assy. | $1,086.54 | Add to Cart |
| 20 | 838156 | Valve Spring | $26.63 | Add to Cart |
| 21 | 840141 | Stud M8 X 186 | $18.48 | Add to Cart |
| 22 | 840171 | Stud M8 X 200 | $18.99 | Add to Cart |
| 23 | 840887 | Allen Screw M6x30 Din 912 | $1.46 | Add to Cart |
| 24 | 841923 | Plug Screw M12x1,5 Din 908 | $11.40 | Add to Cart |
| 25 | 842476 | Collar Cap Nut M8 | $55.61 | Add to Cart |
| 26 | 850930 | O-ring 16×5 | $3.51 | Add to Cart |
| 27 | 854102 | Intake Valve 38mm | $125.17 | Add to Cart |
| 28 | 854188 | Valve Spring Retainer | $47.23 | Add to Cart |
| 29 | 854193 | Rocker Arm Shaft | $54.39 | Add to Cart |
| 30 | 854224 | Valve Guide 912s | $21.31 | Add to Cart |
| 31 | 854387 | Rocker Arm Left | $344.83 | Add to Cart |
| 32 | 854397 | Rocker Arm Right | $344.83 | Add to Cart |
| 33 | 854585 | Exhaust Valve 32mm | $313.32 | Add to Cart |
| 34 | 854862 | Valve Push-rod Assy., | $85.99 | Add to Cart |
| 35 | 866270 | Knock Sensor | $404.91 | Add to Cart |
| 36 | 866714 | Tie Wrap 142×3,2 Mm | $0.08 | Add to Cart |
| 37 | 881832 | Hydraulic Valve Tappet Set | $1,260.83 | Add to Cart |
| 38 | 924440 | Oil Return Tube | $14.17 | Add to Cart |
| 39 | 926210 | Shim 16/27.4/1 | $2.30 | Add to Cart |
| 40 | 927941 | Washer 6,0/12/1 | $0.27 | Add to Cart |
| 41 | 933396 | Bushing Vespel | $81.47 | Add to Cart |
| 42 | 940483 | Hex. Screw M8x30 | $0.45 | Add to Cart |
| 43 | 942302 | Hex. Nut M8 | $53.01 | Add to Cart |
| CAMSHAFT | 230810, 250285, 253092, 430205, 431570, 623756, 623766, 838156, 840141, 840171, 840887, 841923, 842476, 850930, 854102, 854188, 854193, 854224, 854387, 854397, 854585, 854862, 881832, 881920, 924440, 926210, 927941, 933396, 942302 |
|---|
